Dry Verge Universal Cap Angled Grey

The Ubbink Universal Dry Verge is a mortar free system to mechanically fix the verge tiles according to BS5534. It is quick and easy to install. The units have a water channel built in to prevent water staining, often a common issue with other dry verge systems. With a batten gauge of 255mm to 355mm the system suits most popular profile tiles including the thin leading edge tile. Included in the system is a batten bracket, which gives a secure fixing to the end of the cut flush batten ensuring there is a straight/equal install line for the verge. The system suits roof pitches up to 55° and is easy and quick to install. It offers integral solutions for a secure fixing to the roof. The unique starter unit at the eaves offers three different installation options: fixing to the barge board; to the fascia board; or to the lowest batten It can also be installed with or without the gutter in place.

• Each ambi unit has a water drip channel, preventing water staining
• Suits popular profile roof tiles with a batten gauge range of 255mm to 355mm
• Suits the thin leading edge tile (additional cutting is required on ambi unit tabs)
• The starter unit gives a positive fixing point for the system and can be installed either with or without the gutter in place
• The batten bracket gives a secure fixing to the end of the batten. Also no measuring is required for the 30mm overhang of the batten as the batten bracket abuts a flush cut batten
• Suits roof pitches up to 55°
