Haelix Quadro Valve 125mm

Article number: 188061

Haelix-Quadro (3)
design_valve_assembly_Square front
design_valve_assembly_Square front no topcap
design_valve_assembly_Square in bedroom close-up
design_valve_assembly_Square in bedroom
Dimensional drawing – Haelix Quadro Valve 125mm
design_valve_assembly_Square exploded
Haelix-Quadro (3)
design_valve_assembly_Square front
design_valve_assembly_Square front no topcap
design_valve_assembly_Square in bedroom close-up
design_valve_assembly_Square in bedroom
Dimensional drawing – Haelix Quadro Valve 125mm
design_valve_assembly_Square exploded

A stylish and high performance design extract and supply valve DN125 (RAL 9016), which can be inserted into the Air Excellent valve adaptors.

  • For both air supply and extract
  • Contemporary design
  • Paintable
  • Easy installation
  • Easy adjustment with 9-step air flow restrictor
  • Low pressure drop
  • Low sound level
  • Flange to prevent dust deposits
View all specifications

Detailed information

The Haelix valve, with its contemporary design, is the final touch to any residential ventilation system. It is available in both a round and square version and fits into ductwork DN125mm. It has been designed to make use of the so-called Coanda effect to optimise the distribution of air and it has a flange to prevent dust deposits on the ceiling. Haelix has a 9-step air flow restrictor, but when used with Air Excellent only needs to be inserted into the valve adaptors because the airflow is set by using the internal air restrictor rings in or external air restrictor valves on the distribution boxes.

Specifications

General

Product Name
Haelix Quadro Valve 125mm
GTIN
8713645222684
Type
Valves & Grilles
Trade name
Haelix

Technical

Comm. Dimension
125 mm / 50 x 100 mm / 60 x 130 mm / 75 mm / 90 mm
Material
Plastic
Colour
White
Airflow direction
Supply / extract

Dimensions

Length gross
230 mm
Height
60 mm
Width
230 mm
Net weight
0.34 kg

Logistical

Intrastat
39259080
Base unit packaging
Box
Packaging / Trade length
255 mm
Packaging / Trade height
65 mm
Number per packaging
1
Gross weight
0.45 kg
Packaging / Trade width
240 mm

Performance

Extract capacity
75 m³/h
Temperature resistance (min.)
5 °C
Supply capacity
75 m³/h
Temperature resistance (max.)
60 °C
