Aerfoam 150 Bend 15°

Article number: 188270

Aerfoam-Bend-15
Aerfoam insulated ductwork system
Installation EPE
Aerfoam-Bend-15
Aerfoam insulated ductwork system
Installation EPE

Aerfoam is an easy-to-install, insulated and airtight ductwork system used in central mechanical ventilation and heat pump systems, which minimises the risk of condensation in or on the duct (airtightness class D = ATC 2 up to +/- 200 Pa).

  • Insulated
  • Extremely easy and safe to cut to length
  • Airtight mechanical connections, which are extremely easy to install
  • Airtightness class D/ATC 2 up +/- 200 Pa, which minimises fan energy use and sound production
  • EPD certified and REACH compliant
View all specifications

Specifications

General

Product Name
Aerfoam 150 Bend 15°
GTIN
8713645123028
Comm. Dimension
150 mm
Trade name
Aerfoam

Technical

Comm. Dimension
150 mm
Material
EPE
Colour
Grey
Insulation thickness
16 mm

Dimensions

Length gross
197 mm
Height
165 mm
Width
182 mm
Net weight
0.04 kg

Logistical

Intrastat
39259080
Base unit packaging
Unpacked
Packaging / Trade length
197 mm
Packaging / Trade height
165.1 mm
Number per packaging
8
Gross weight
0.04 kg
Packaging / Trade width
182 mm

Performance

Temperature resistance (min.)
-30 °C
Installation temperature (min.)
-30 °C
Temperature resistance (max.)
60 °C
Installation temperature (max.)
60 °C
