Air Excellent DBOX Stepped Adaptor 100-125

Article number: 188637

188637-DB200-V125
188637-DB200-V125

An Air Excellent distribution box accessory used to connect mass flow ductwork to Air Excellent distribution boxes.

  • Low system pressure loss due to radial design
  • Airtightness class D/ATC 2 up +/- 2000 Pa, which minimises fan energy use and sound production
  • Modular manifolds, which can be used with all duct types
  • Semi-rigid ducts on a roll and airtight mechanical connections, which are extremely easy to install
  • TÜV SÜD and ISEGA tested and certified, REACH compliant
View all specifications

Specifications

General

Product Name
Air Excellent DBOX Stepped Adaptor 100-125
GTIN
8713645217130
Type
Adaptors
Trade name
Air Excellent

Technical

Comm. Dimension
100 mm
Material
PP
Colour
Grey

Dimensions

Net weight
0.07 kg

Logistical

Intrastat
39259080
Base unit packaging
Box
Packaging / Trade length
262 mm
Packaging / Trade height
181 mm
Number per packaging
1
Gross weight
0.31 kg
Packaging / Trade width
201 mm
